HG-CSW10 2P8

คุณสมบัติสินค้า:

PoE(1-8) up-Link(7-8)/LAN1-2, 1000Mbps Full Duplex; 100 or 1000Mbps Half Duplex, Network Interface: 10BASE-T or 1000BASE-TX RJ45 port of Ethernet Bandwidth:9.2 Gbps (no barriers), Network Latency (10 to 1000Mbps):, IEEE 802.3i 10BASE-T, Default: 1/2(+), 3/6(-); (Can Be Selected 4/5(+), 7/8(-)), Power input: AC 180~240V 120W / Power input: PoE port 1-8 1/2 (+52V)

Share


  • Using CAT.5 network cable support power for the Access Point and IP camera
  • Networking standard IEEE802.3af/t
  • Long distance transmission and power supply, maximum transmission distance is 130m
  • Upload port support Auto MDI / MDIX
  • Forwarding Mode: Store-and-forward
  • Intelligent power distribution and secure power supply system
  • Power circuit protection function can protect environment
  • Zero configuration feature power supply is automatically supplied to the adaptive eguipment
  • Professional thunder design, Overtemperature protection, short circuit protection, high reliability, high stability
  • Nature cooling, amall, compact, mute, all the design are convenient for you put
  • Support: port no-load saving power

ModelHG-CSW10 2P8
Network InterfacePoE (1-8) up-Link (7-8) LAN1-2
Network StandardIEEE802.3af, IEEE802.3at
Transmission Rate

Network Interface: 10BASE-T or
1000BASE-TX RJ45 port of ethernet

Perfomance&SpecificationBandwidth:9.2 Gbps (no barriers Network Latency (10 to 1000Mbps)< 20 (use the 64 byte packge size)
MAC address table: 8K
The frame Filter & Transmission Rate
14800pps the most for 10M port
148000pps the most for 100M port"
Network SandartEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x Flow Control
IEEE 802.3af/at Power over Ethernet
PoE Core of Power CableDefault: 1/2(+), 3/6(-) (Can Be Selected 4/5(+), 7/8(-)
Power SupportPower input: AC 180-240V/120W
Power output: PoE1-8Port1/2(+52V),3/6(GND),DC 5525 5V1A
Phisical SpecificationSize (LxWxH) 310mm x 260mm x 100mm
Working EnvironmentOperating Temperature -10 ํC-+55 ํC (-14 ํ-131 ํF)
Storage Temperature -40 ํC-+70 ํC (-104 ํ-158 ํF)
Operating Humidity 10%-90% non-condensing
Storage Humidity 5%-90% non-condensing
Electromagnetic CompatibilityCE mark
FCC Part 15, Class B
VCCI Class B EN 55022 (CISPR 222)
C-Tick
WarranthyWhole machine: 1 Year
Package ContentAC Power Cable Installation Manual Warranthy Card
