HS-320P Solar Cell Panels 320W Poly Cystaline

คุณสมบัติสินค้า:

Maximum Power (W) 320, Tolerance (%) 0/+3%, Open Circuit Voltage (V) 45.7, Short Circuit Current (A) 8.94, Maximum Power Voltage (V) 37.7, Maximum Power Current (A) 8.49, Module Efficiency (%) 16.5, Solar Cell Efficiency (%) 18.3, Series Fuse Rating (A) 15, Terminal Box IP65, Maximum system voltage (V) DC1000, Operating Temperature(℃) -40℃ -85℃, Current Temperature, Coefficiant %/℃ +0.06, Voltage Temperature, Coefficient %/℃ -0.34, Power Temperature, Coefficient %/℃ -0.47, Dimension: 1956*992*35MM, Weight: 21KG/PCS, Packing : 2pcs in one carton, Performance Warranty : 12 years, 90% output , 25years, 80% output

Share

หมวดหมู่ : SOLAR CELL

Share

  •  Maximum Power (W) 320
  • Tolerance (%) 0/+3%
  • Open Circuit Voltage (V) 45.7
  • Short Circuit Current (A) 8.94
  • Maximum Power Voltage (V) 37.7
  • Maximum Power Current (A) 8.49
  • Module Efficiency (%) 16.5
  • Solar Cell Efficiency (%) 18.3
  • Series Fuse Rating (A) 15
  • Terminal Box IP65
  • Maximum system voltage (V) DC1000
  • Operating Temperature(℃) -40℃ -85℃
  • Current Temperature
  • Coefficiant %/℃ +0.06
  • Voltage Temperature
  • Coefficient %/℃ -0.34
  • Power Temperature
  • Coefficient %/℃ -0.47
  • Dimension: 1956*992*35MM
  • Weight: 21KG/PCS
  • Packing : 2pcs in one carton
  • Performance Warranty :
  • 12 years, 90% output ,
  • 25years, 80% output,
