HP-97S50PE-AI กล้องวงจรปิดไฮวิว กล้องตรวจจับใบหน้า ระบบไอพี 5 ล้านพิกเซล ใช้งานภายนอกและภายใน Hiview Bullet AI Technology IP Camera PoE 5 MP

คุณสมบัติสินค้า:

1/2.5" CMOS progressive scan / 5MP, Video Compression H.265, H.265+, H.264, H.264+, MJPEG, Day / Night Mode Auto / day / night / timing, IR-CUT Filter Supported, Smart IR Supported (On/Off), Video Encode Slice Split Supported, Water Mark / OSD Supported, Date and Time Supported, Video Mask Supported (Max. 4 areas), ROI Supported (Max. 3 areas), Face Computing 3-5 face/Sec, Free DDNS www.autoddns.com, dvrdydns, Etc., SD-Card Slot x1 (Max. 128GB), Power Supply AC24V/12V DC +-10% / PoE (IEEE802.3af)

หมวดหมู่ : CAMERA IP CAMERA

Share

  • 1/2.5" CMOS progressive scan / 5MP
  • Video Compression H.265, H.265+, H.264, H.264+, MJPEG
  • Day / Night Mode Auto / day / night / timing
  • IR-CUT Filter Supported
  • Smart IR Supported (On/Off)
  • Video Encode Slice Split Supported
  • Water Mark / OSD Supported
  • Date and Time Supported
  • Video Mask Supported (Max. 4 areas)
  • ROI Supported (Max. 3 areas)
  • Face Computing 3-5 face/Sec
  • Free DDNS www.autoddns.com, dvrdydns, Etc.
  • SD-Card Slot x1 (Max. 128GB)
  • Power Supply AC24V/12V DC +-10% / PoE (IEEE802.3af)
  • ดาวน์โหลดสเปคสินค้า Hiview HP-97S50PE-AI ที่นี่
ModelHP-97S50PE-AI
Image Sensor1/2.5" CMOS progressive scan
Pixels5MP
Min. lllumination

0.0.36 lux@F2.0, AGC ON, 0.009 lux@F2.0, AGC ON

0.013 lux@F1.2, AGC ON, 0.003 lux@F1.2, AGC ON

Lens
Mount TypeC/CS
Iris TypeAuto iris, DC drive
Infrared
Day / NightMode Auto/day/night/timing
IR-CUT FilterSupported
Smart IRSupported (On/Off)
Display
Image Parmeter3 type (common, day, night) and schedule setting
Brihtness AdjustSupported
Contrast AdjustSupported
Hue AdjustSupported
Saturation AdjustSupported
Sharpness AdjustSupported
Noise ReductionSupported 3D DNR
DefogSupported
WDR / HWDRSupported 120dB
BLC / HLCSupported
HFR ModeSupported (1080P @50fps/PAL, 60fps/NTSC)
Anti-FilckerSupported 50Hz/60Hz
White BalanceSupported (Auto/indoor/outdoor/manual)
FrequencySupported 50Hz/60Hz
Exposure ModeSupported auto/manual (1/25s-1/100,000s)
GainSupported
Corridor PatternSupported 0/90/180/270
Image MirrorSupported
Image FlipSupported
Backlight CompensationSupported
E-zoomSupported
Images
Video CompressionH.265, H.265+, H.264, H.264+, MJPEG
Audio CompressionG711A, G711U
Compression StandardBase line, Main Profile, High Profile
StreamTriple stream
Image Resolution

Main stream 2592x1944, 2592x1520, 2560x1440,2304x1296, 1920x1080, 1280x720

Sub stream 1280x720, 704x576, 352x288

Third stream 704x576, 480x240, 352x288

Image Frame Rate

Main stream 2592x1944, 2592x1520, 2560x1440, 2304x1296, 1920x1080, 1280x720@25fps(PAL)

Sub stream 1280x720@15fps(PAL), 704x576@25fpa(PAL), 352x288@25fps(PAL)

704x576@25fps(PAL), 352x288@25fps(PAL)

Third stream 704x576, 480x240, 352x288@25fps(PAL)

Video Encode Slice Split

Supported

Water Mark

Supported

OSD

Supported

Date and Time

Supported DST, NTP, synchronize with PC,manual

Video Mask

Supported (Max. 4 areas)

ROI

Supported (Max. 3 areas)

Face Detection
Face Detection

Pupil distance of a facial image over 80 pixel can be detected

Face Computing

3-5 face/Sec

Facde Capturing Distance

Recommended distance 3-5 meters (Depends on lens)

Face Capturing

By precision detecting, tracing, capturing, scoring and screening the moving faces to get the most effective face snapshots

Intelligent Light Compensation

Built-in high efficient light LEDs, time switch available

Alarm
Motion Alarm

Supported

Motion Sensitivity

Supported

Motion Schedule Setting

Supported

Motion Alarm Triggering

Alarm out/trigger snap/SD card record//email/FTP

SD Card Full  Alarm

Supported

SD Card Error Alarm

Supported

IP Address Coliision

Supported

Cable Disconnected

Supported

Alarm InputSupported NO/NC
Alarm OutputSupported
Alarm ServerSupported
Network
Network Protocols

IPv4, IPv6, DNS, PPPoE, HTTP, HTTPS, RTSP, DNS, SNMPv1/v2/v3,

802.1X, RTSP, UPNP, SMTP, FTP, QoS, ONVIF, DST, NTP

Test IP Address FunctionSupported
DDNS Protocol

autoddns.com/88ip.net/dns2p.net/meibu.com/dyndns.com/

no-ip.com/dvrdydns/mindns/123ddns.com

Free DDNSwww.autoddns.com, dvrdydns, Etc.
Application ProgrammingONVIF profile S
IP Change NotificationSupport (Tringering email, FTP)
Online ConnectionSupport simultaneous monitoring for up to 6 users
User InterfaceIE 11,NVMS2.0, APP (Superliveplus)
Storage
Record SourchSD-Card slot
Record StreamTriple stream (main,sud, thrid stream)
Pre Record Time3, 6secs (H.264,H265,MJPEG)
Cycle WriteSupported
Record TimningSupported week schedule/ holiday schedule
SnapshotSupported JPEG
Snapshot Resolution704x576
Snapshot Event TriggerSupported
Snapshot Event scheduleSupported week schedule/ holiday schedule
PTZ
ProtocolPELCO D, PELCO P
Adreess1-255
Baud-Rate

110/300/600/1200/2400/4800/9600/19200/38400/

57600/115200

Security
User Account ManagementSupported
IP/MAC Address FilterSupport (black and white list)
Locking Once lllegal LoginSupported
Online User CheckingSupported Kick-off
Maintenance
Backup and RestoreSupported export/import setting, load default
RebootSupported time/date schedule
System UpgradeSupported
Log SerachSupported export log
Interfaces
RJ45x1 (Speed 100Mbps), POE
Audio Inputx1 (Jack 3.5)
Audio Outputx1 (Jack 3.5)
SD-Card Slotx1 (Max. 128GB)
BNC Outputx1
Hardware Reset Buttomx1
Alarm Inputx1
Alarm Outputx1
RS485x1
Power Inputx1 (DC jack)
Environmental
Operating Temperature-30ํC-+50ํC
Operating Humidyty95% or less (non-condensing)
Electrical
Power SupplyAC24V/12V DC +- 10% / PoE (IEEE802.3af)
Power Consumption40mA/4.5W
Mechanical
WeightApprox. 0.67KG
Dimensions138.4x70.0x60.5mm.
