HA-304B20ST กล้องวงจรปิดไฮวิว 2 ล้านพิกเซล ใช้งานภายนอกและภายใน บันทึกภาพสีแม้แสงน้อย (Hiview Bullet Starlight Camera 2 MP 4 in 1)


AHD Bullet Camera 2 MP (1920x1080) ,Sony 1/2.8" IMX291 CMOS Sensor Progressive Scan ,0.0001 Lux / IP66 , Surge Protection 5000 Volt , Support OSD (HLC/D-WDR) , PAL/NTSC Lens size 3.6mm. , IR LED 36 Pcs. / 30M. ,Day&Night Support color, B/W, Auto, Ext adjustable Power Input DC12V±10% ,มี IR

หมวดหมู่ : CAMERA AHD CAMERA 1080P


** สินค้ากล้องวงจรปิดไม่รวมอะแดปเตอร์**

SolutionSony 1/2.8" IMX291 CMOS progressive Sensor
Video formatPAL/NTSC
Video resolution1920x1080P
Effecttive pixel2.13MP.
CVBS resolution960 CVBS output (1000TVL.)
CVBS CometSupprt
Min.illuminationColor: 0.001 lux@(F1.2, AGC ON) 0 lux with IR
Electric shutterAuto: PAL 1/50-1/100,000Sec
Frame rate"30fps@60Hz / 25fps@50Hz''
S/N ratio>52dB. (AGC OFF)
Ingress proteionIP66
Lens size3.6mm.
F/No. / Lens mountF1.2 / M12
IR typeIR LED 36 Pcs.
IR distance30M.
Day&NightSupport color,B/W, Auto adjustable
ICR SiwtchSupport IR filter (IR-CUT)
IR SmartSupport
Hardware interface
Video outputBNC female x1 (1.0 Vp-p Composite (75)
Power inputDC Jack x1
CableOSD Caable
Power supplyDC12V(+-10%)
Power consumptionIR OFF: 50 mA / IR ON: 30mA.
Surge protectionSupport ESD surge protection up to 5000Volt
Working environment-10ํC to +50ํC
Storage Temp-20ํC to +60ํC
Working humidity10% to 90%
Casing materialMetal
